ALLIED TELESIS 48V 480W DIN RAIL POWER SUPPLY
INDUSTRIAL SWITCH 48V 480W SINGLE OUTPUT INDUSTRIAL DIN RAIL POWER SUPPLY
- Brand: ALLIED TELESIS
- Category: Power Supplies
- SKU: 5232214
- MPN: AT-IE048-480-20
Allied Telesis AT-IE048-480-20 uninterruptible power supply (UPS)… Save $219.01 off RRP
Available On OrderAsk us for ETA
$622.14
Inclusive of GST
1
4 payments of $155.54Value Deal
Low prices and fast dispatch on every order. Seen it cheaper? Request a price match.
Shipped to your region. Freight is calculated at checkout from live courier rates.
Standard delivery to main‑centre, ground‑floor addresses is included in the quoted rate. For rural or oversized deliveries, any extra freight will be confirmed before dispatch.
Collection available — we'll confirm pickup readiness after your order:
- 136 Cryers Road, East Tāmaki, Auckland 2013
Key Details:
- SKU:
- CNZ-IM-020535
- MPN:
- AT-IE048-480-20
- Brand:
- ALLIED TELESIS
We accept
On Sale
Genuine NZ stock with full manufacturer warranty — no parallel imports. Save $219.01 off RRP while stocks last.
ALLIED TELESIS 48V 480W DIN RAIL POWER SUPPLY
The ruggedized IE048-480 industrial power supply is a functional accessory for Allied Telesis products to build a solution suitable for Smart Cities (e.g. Surveillance & Security), Industrial Ethernet, Transportation or any application requiring systems that function in harsh environment with extended operating temperature.
The IE048-480 is a power supply delivering reliable 480W output power at 48Vdc; it was fully tested and validated to operate with Allied Telesis Industrial products.
Housed in compact metal case with DIN-rail clip, it takes special account of the mechanical robustness, electromagnetic compatibility and thermal characteristics to exhibit the required strengths to work satisfactorily in harsh environment where it will be exposed
Its highly efficient and stable output power has the capability to support 150% of peak load. The nominal output voltage of 48Vdc can be adjusted to match the application requirements.
The AC/DC rectifier operates over the full range of AC input voltage to fit worldwide power grids. The included active Power Factor Correction circuit (PFC) reduces energy costs by eliminating reactive power and harmonics from power lines. Besides the increment of efficiency, PFC is to comply with international regulations, which established limits on harmonic currents that can appear on the AC main line.
The IE048-480 is a power supply delivering reliable 480W output power at 48Vdc; it was fully tested and validated to operate with Allied Telesis Industrial products.
Housed in compact metal case with DIN-rail clip, it takes special account of the mechanical robustness, electromagnetic compatibility and thermal characteristics to exhibit the required strengths to work satisfactorily in harsh environment where it will be exposed
Its highly efficient and stable output power has the capability to support 150% of peak load. The nominal output voltage of 48Vdc can be adjusted to match the application requirements.
The AC/DC rectifier operates over the full range of AC input voltage to fit worldwide power grids. The included active Power Factor Correction circuit (PFC) reduces energy costs by eliminating reactive power and harmonics from power lines. Besides the increment of efficiency, PFC is to comply with international regulations, which established limits on harmonic currents that can appear on the AC main line.
Key features
- Output power: 480 W
- Input operation voltage (min): 90 V
- Input operation voltage (max): 350 V
- Input frequency: 50/60 Hz
- Output operation voltage (max): 48 V
- Maximum current: 15 A
- Efficiency: 94%
- Power factor: 0.98
- Power protection features: Over current, Over voltage, Overheating
- Form factor: Tower
- Housing material: Metal
- Cooling type: Active
- Product colour: White
- LED indicators: Alarm, Status
- Operating temperature (T-T): -20 - 70 °C
- Storage temperature (T-T): -40 - 85 °C
- Operating relative humidity (H-H): 20 - 90%
- Storage relative humidity (H-H): 20 - 90%
- Compliance certificates: RoHS, WEEE
- Width: 70 mm
- Depth: 117 mm
- Height: 124 mm
- Weight: 1.2 kg
- Export Control Classification Number (ECCN): 5A992C
- Harmonized System (HS) code: 8504.40.8500
- Nominal output voltage: 48 V
- Nominal input voltage: 90 - 264; 98 - 350 V
