APC RACK PDU BASIC 1 U 16A 230V power distribution unit (PDU) 12 AC…

Name: APC BASIC 1U RACK PDU, 240V, 16A, 3.7KW, C13(10), C19(2), IEC-320 C20, 2YR
Brand: APC
SKU: AP9559
Price: 885.49 NZD
Availability: BackOrder

APC RACK PDU BASIC 1 U 16A 230V, Basic, 0U/1U, Single-phase, Horizontal/Vertical, Black, 12 AC outlet(s)

Click or hover over image to enlarge

Brand:APC

MPN:AP9559

Part #: AP9559

Search this part on Google

Load capacity

3680 VA

Maximum input current per phase

16 A

Maximum power

3680 W

PDU types

Basic

Type

Single-phase

Rack capacity

0U/1U

Mounting

Horizontal/Vertical

Product colour

Black

Returns & Warranty

Comsys Price

$885.49

On Sale

Save $59.01 off RRP

Available to Order

Ships in 1–5 business days

NZ-wide deliveryNZ Post rates·Ships from Auckland, 1–3 days

100% NZ Owned & Operated

Shipped to your region. Freight is calculated at checkout from live courier rates.

Standard delivery to main‑centre, ground‑floor addresses is included in the quoted rate. For rural or oversized deliveries, any extra freight will be confirmed before dispatch.

Add To Compare

We accept

Four payments of $221.37 per fortnight

Value Deal

Fast dispatch and fair pricing on every order. Found a better offer? Ask for a match.

Secure Checkout

Trusted payment methods and encrypted transactions.

Technical Support

Pre-sales and post-sales support from our team.

Warranty Backed

Local warranty handling and straightforward returns.

APC BASIC 1U RACK PDU, 240V, 16A, 3.7KW, C13(10), C19(2), IEC-320 C20, 2YR

Description:

APC Basic Rack PDU, Input : 120, 208, 230V , Input Connection Type : IEC-320 C20 , Cord Length : 8.2 feet ( 2.5 meters ) , Output : 120, 208, 230V , Output Connections : (10)IEC 320 C13, (2)IEC 320 C19

Features: 19 inch Rack-Mountable, Low Cost Power Distribution, Vertical Mounting Capabilities

Includes: Cord Retention Clips, Rack Mounting Brackets, User Manual

Output Voltage(s) (main only) - 120, 208, 230 V

Maximum Total Current Draw per Phase - 16 A

Output Connections - (10)IEC 320 C13; (2)IEC 320 C19

Always on Outlets - 12
Overload Protection

Input:

Nominal input voltage - 120, 208, 230

Input frequency (Hz) - 50/60 Hz

Input Connection Type - IEC-320 C20

Cord Length 8.2 feet ( 2.5 meters )

Acceptable Input Voltage - 90-250 VAC

Maximum Line Current per phase - 16.0 A

Maximum Input Current per phase - 16.0 A

Load Capacity - 3680

Key features

PDU types: Basic
Type: Single-phase
Rack capacity: 0U/1U
Mounting: Horizontal/Vertical
Product colour: Black
AC outlets quantity: 12 AC outlet(s)
Power plug: C20 coupler
AC outlet types: C13 coupler, C19 coupler
I/O ports: Output Connections - (10)IEC 320 C13; (2)IEC 320 C19 Input Connection Type - IEC-320 C20
Cable length: 2.5 m
Load capacity: 3680 VA
Maximum input current per phase: 16 A
Maximum power: 3680 W
Operating temperature (T-T): 0 - 45 °C
Storage temperature (T-T): -25 - 65 °C
Operating relative humidity (H-H): 0 - 95%
Storage relative humidity (H-H): 0 - 95%
Width: 447 mm
Depth: 57.2 mm
Height: 44.5 mm
Weight: 980 g
