APC Easy PDU 2G Metered-by-Outlet with ZeroU

Easy PDU 2G Metered-by-Outlet with Switching ZeroU 22kW 230V (18) C13 and (6) C19

  • Brand: APC
  • Category: UPS Systems
  • SKU: 6181724
  • MPN: EPDU2232SMBO
APC Easy PDU 2G Metered-by-Outlet with ZeroU — APC — Power & UPS > UPS Systems

APC Easy Rack PDU, Switched Metered Outlet, 0U, 3 Phase, 22kW, 230V,… Save $476.01 off RRP

Available to Order
$3,075.09

Inclusive of GST

1
Afterpay4 payments of $768.77
Value Deal

Low prices and fast dispatch on every order. Seen it cheaper? Request a price match.

Shipped to your region. Freight is calculated at checkout from live courier rates.

Standard delivery to main‑centre, ground‑floor addresses is included in the quoted rate. For rural or oversized deliveries, any extra freight will be confirmed before dispatch.

Key Details:

Model:
EPDU2232SMBO
Part #:
6181724
Brand:
APC

Ask Our Experts:

Ask a question about this item Request a price match
We acceptVisaMastercardAmerican ExpressApple PayGoogle PayAfterpay
On Sale

Genuine NZ stock with full manufacturer warranty — no parallel imports. Save $476.01 off RRP while stocks last.

APC Easy PDU 2G Metered-by-Outlet with ZeroU

Easy rack PDU Metered-by-Outlet with Switching EPDU2232SMBO provides advanced power monitoring and control capabilities for individual outlets, empowering critical IT infrastructure. The Network Management Card NMC3 provides enhanced cybersecurity with secured interfaces and modified password policy. The rack PDU integrates with EcoStruxure IT through a Network Management Card (NMC3) and can be accessed and configured via Web, SNMP, and Command Line Interface. EPDU2232SMBO is designed for three phase applications of upto 22kw and industry standards of 1% metering accuracy. This comes with IEC 603093 32A 3P+N+PE type inlet, eighteen IEC C13 and six IEC C19 type outlet sockets. It features an ultra-lightweight aluminum housing, offering up to 50% weight reduction, along with environmental monitoring and an all-new improved display module. Vertical mounting capabilities allow users to mount the units in a rack or enclosure in zero U space without expending valuable rack space This is designed to operate within a temperature range of -5°C to +50°C and is backed by a standard 2-year warranty. Remotely manage outlets so users can turn outlets off that are not in use (prevent overloads) or recycle power to locked-up equipment (minimize costly downtime and avoid travel time to equipment) The rack PDU supports daisy-chain of up to 4 PDUs on a single IP address, thereby reducing networking cost.

Key features

  • PDU types: Metered, Switched
  • Type: Three-phase
  • Rack capacity: 0U
  • Mounting: Vertical
  • Housing material: Metal
  • Product colour: Black
  • Display: LCD
  • AC outlets quantity: 24 AC outlet(s)
  • Power plug: IEC 60309
  • AC outlet types: C13 coupler, C19 coupler
  • Ethernet LAN (RJ-45) ports: 1
  • USB ports quantity: 1
  • Cable length: 3 m
  • Nominal input voltage: 400 V
  • AC input frequency: 50/60 Hz
  • Maximum current: 32 A
  • Output voltage: 200-240 V
  • Load capacity: 22000 VA
  • Power protection features: Overload
  • Operating temperature (T-T): -5 - 45 °C
  • Storage temperature (T-T): -25 - 65 °C
  • Operating relative humidity (H-H): 5 - 95%
  • Storage relative humidity (H-H): 5 - 95%
  • Operating altitude: 0 - 15000 m
  • Width: 55 mm
  • Depth: 56 mm
  • Height: 1800 mm
  • Weight: 8.68 kg
  • Package weight: 9.85 kg
  • Package width: 195 mm
