APC Easy Rack PDU, Basic, 0U, 1 Phase, 7.4kW, 230V, 32A, 20 x C13…

Name: APC EASY PDU, BASIC, ZERO U, 32A, 230V, (20)C13 & (4)C19?IEC309
Brand: APC
SKU: EPDU1132B
Price: 514.04 NZD
Availability: InStock

APC Easy Rack PDU, Basic, 0U, 1 Phase, 7.4kW, 230V, 32A, 20 x C13 and 4 x C19 outlets, IEC60309 2P+E inlet, Basic, 0U, Single-phase, Vertical, Aluminium, Black

Click or hover over image to enlarge

Brand:APC

MPN:EPDU1132B

Part #: EPDU1132B

Search this part on Google

Nominal input voltage

200/208/230 V

AC input frequency

50 - 60 Hz

Maximum current

32 A

Nominal output voltage

230 V

Load capacity

7360 VA

Maximum input current per phase

32 A

PDU types

Basic

Type

Single-phase

Returns & Warranty

Comsys Price

$514.04

On Sale

Save $152.01 off RRP

In Stock

21 units available

NZ-wide deliveryNZ Post rates·Ships from Auckland, 1–3 days

Shipped NZ‑wide. Freight is calculated at checkout from live courier rates; delivery within Auckland is free on standard‑size items.

Standard delivery to main‑centre, ground‑floor addresses is included in the quoted rate. For rural or oversized deliveries, any extra freight will be confirmed before dispatch.

Add To Compare

We accept

Four payments of $128.51 per fortnight

Value Deal

Fast dispatch and fair pricing on every order. Found a better offer? Ask for a match.

Secure Checkout

Trusted payment methods and encrypted transactions.

Technical Support

Pre-sales and post-sales support from our team.

Warranty Backed

Local warranty handling and straightforward returns.

APC EASY PDU, BASIC, ZERO U, 32A, 230V, (20)C13 & (4)C19?IEC309

APC Easy Basic Rack PDU EPDU1132B is Easy-to-install and easy-to-use PDU, making rack power distribution easy. This offers more than a power strip for server rack and network rack solutions. This is Vertical rack mountable PDU in ultra light weight upto 50% weight reduction with Aluminum housing. This is integrated with Hydraulic-magnetic circuit breakers (in units with 32A input current). EPDU1132B has IEC 309 32A 2P+E type inlet, Twenty IEC C13 and four IEC C19 type outlet sockets. This can operate from -5° to +45°C temperation range and comes with 1 year of standard warranty. Easily mounts vertically in racks or enclosures and occupies zero U of valuable rack space, which allows more equipment in the rack. The packaging includes installation guide, toolless mounting kit and mounting brackets for quick and easy mounting in the rear of the enclosure. Product family includes a variety of input and output connections to distribute 120V, 208V, or 230V power to multiple outlets. Saves time and money during installation by using one branch whip and standard connections. Having a variety of inputs and outputs allow users to adapt to varying power requirements. APC offers units that bring up to 17.3kW using a single branch whip.

Key features

PDU types: Basic
Type: Single-phase
Rack capacity: 0U
Mounting: Vertical
Housing material: Aluminium
Product colour: Black
On/off switch: No
AC outlets quantity: 24 AC outlet(s)
Power plug: IEC 60309
AC outlet types: C13 coupler, C19 coupler
Nominal input voltage: 200/208/230 V
AC input frequency: 50 - 60 Hz
Maximum current: 32 A
Nominal output voltage: 230 V
Load capacity: 7360 VA
Maximum input current per phase: 32 A
Certification: CE, TUV
Operating temperature (T-T): 0 - 45 °C
Storage temperature (T-T): -25 - 65 °C
Operating relative humidity (H-H): 5 - 95%
Storage relative humidity (H-H): 5 - 95%
Operating altitude: 0 - 3000 m
Non-operating altitude: 0 - 9000 m
Width: 62 mm
Depth: 44 mm
Height: 1175 mm
Weight: 3.58 kg
Manual: Yes
Package weight: 4.36 kg
Package width: 160 mm

+ 3 more — see the Specifications tab.
