ATEN 4 PORT VGA INPUT BOARD FOR VM1600A/VM3200

Networking > Network Accessories

  • Brand: ATEN
  • Category: Networking
  • SKU: VM7104-AT
  • MPN: VM7104-AT

ATEN 4-Port VGA Input Board for VM1600 / VM3200

ATEN 4-Port VGA Input Board for VM1600 / VM3200, VGA, Metal, Black, Green, 1920 x 1200 (WUXGA), 300 MHz, 1920 x 1200 pixels

ATEN 4 PORT VGA INPUT BOARD FOR VM1600A/VM3200

Click or hover over image to enlarge

Brand:ATEN
MPN:VM7104-AT

Part #: VM7104-AT

Search this part on Google

Power consumption (typical)

7.1 W

Material

Metal

Product colour

Black, Green

Supported graphics resolutions

1920 x 1200 (WUXGA)

Bandwidth

300 MHz

Maximum resolution

1920 x 1200 pixels

Manual

Yes

Video port type

VGA

Returns & Warranty

Comsys Price

$2,444.89
On Sale

Save $437.48 off RRP

Available to Order

Ships in 1–5 business days

NZ-wide deliveryNZ Post rates·Ships from Auckland, 1–3 days
1
100% NZ Owned & Operated

Shipped to your region. Freight is calculated at checkout from live courier rates.

Standard delivery to main‑centre, ground‑floor addresses is included in the quoted rate. For rural or oversized deliveries, any extra freight will be confirmed before dispatch.

Add To Compare
We acceptVisaMastercardAmerican ExpressApple PayGoogle PayAfterpay
Afterpay

Four payments of $611.22 per fortnight

Value Deal

Fast dispatch and fair pricing on every order. Found a better offer? Ask for a match.

Secure Checkout

Trusted payment methods and encrypted transactions.

Technical Support

Pre-sales and post-sales support from our team.

Warranty Backed

Local warranty handling and straightforward returns.

ATEN 4 PORT VGA INPUT BOARD FOR VM1600A/VM3200

The VM7104 4-Port VGA Input Board offers an easy way to route 4 VGA video and audio sources up to 16 displays, when used in combination with the ATEN Modular Matrix Switch. The VM7104 supports RGBHV / RGBS/ Y CbCr/ YPbPr input signals; stereo audio that can be embedded into HDMI Audio output. The board is built with a hot-swappable design that is compatible with the VM1600, so that the unit doesn’t need to be powered off when the board is changed.

- Connects up to 4 VGA or Component inputs
- Supports RGBHV / RGBS/ YCbCr/ YPbPr input signals
- Hot-swappable design for easy integration of I/O boards
- Compatible with the VM1600 and can be mixed with any modular output boards for optimum flexibilit

Key features

  • Video port type: VGA
  • VGA (D-Sub) ports quantity: 4
  • Material: Metal
  • Product colour: Black, Green
  • Supported graphics resolutions: 1920 x 1200 (WUXGA)
  • Bandwidth: 300 MHz
  • Maximum resolution: 1920 x 1200 pixels
  • Power consumption (typical): 7.1 W
  • Width: 328 mm
  • Height: 228 mm
  • Weight: 560 g
  • Length: 352 mm
  • Manual: Yes
  • Operating temperature (T-T): 0 - 40 °C
  • Storage temperature (T-T): -20 - 60 °C
  • Operating relative humidity (H-H): 0 - 80%
