0-30VDC Resistive Dimmer
0-30VDC Resistive Dimmer
- Brand: KIWI
- Category: RAM
- SKU: K001DC
- MPN: K001DC
KIWI 0-30VDC Resistive Dimmer
0-30VDC Resistive Dimmer All you need for low-voltage control of EC Fans and LED Lighting.
Click or hover over image to enlarge
Comsys Price
Save $32.01 off RRP
Only 1 left in stock
Order soon to avoid backorder
Shipped NZ‑wide. Freight is calculated at checkout from live courier rates; delivery within Auckland is free on standard‑size items.
Standard delivery to main‑centre, ground‑floor addresses is included in the quoted rate. For rural or oversized deliveries, any extra freight will be confirmed before dispatch.
Four payments of $14.37 per fortnight
Fast dispatch and fair pricing on every order. Found a better offer? Ask for a match.
Secure Checkout
Trusted payment methods and encrypted transactions.
Technical Support
Pre-sales and post-sales support from our team.
Warranty Backed
Local warranty handling and straightforward returns.
0-30VDC Resistive Dimmer
0-30VDC Resistive Dimmer
All you need for low-voltage control of EC Fans and LED Lighting.
Connect GND, Input low voltage, then connect to the control input of your device, and you will have full control over the entire range.
Default is full range of voltage or set the minimum and or maximum trimmers with the screwdriver supplied, and you will have established the range your customer can control.
Use the KIWI to control the ON/OFF by connecting to the Delay OFF Timer terminal and setting the delay time you require. When the user switches the terminal, the circuit will continue running until the delay times out. The circuit will only come back ON when they switch ON again, removing voltage to the terminal.
Connecting to the High Low terminal ensures the application goes to wherever the maximum trimmer is set. Want a fan to go full speed with delay OFF, link the Delay OFF Timer and High Low together.
Push Button, Momentary Switch dimming, call it what you want, the K001DC does it all, full push button control, and with ease.
Features:
- Standard full range control
- Minimum and Maximum (setable limits)
Recommended for:
- DC Control Circuits
- 5 to 30VDC input
- PWM Full Variable Control & Variable Resistor models
- High Low levels (installer defined)
- Delay OFF Timer (installer set time)
+ EC Fans + LED Lighting
Inc GST
$57.49
