StarTech.com 4-Port HDMI Switch w/Picture-and-Picture
4-Port HDMI Switch with Picture-and-Picture Multiviewer - 4x1 HDMI Video Switch with PAP Video Combining - Combine 4 HDMI Inputs on a Single Display - 1920x1200 / 1080p
- Brand: StarTech.com
- Category: A/V Cables & Adapters
- SKU: 2784145
- MPN: VS421HDPIP
StarTech.com 4-Port HDMI Switch with Picture-and-Picture Multiviewer
Available On OrderAsk us for ETA
Contact us for pricing
Sales will confirm current pricing and availability
Value Deal
Low prices and fast dispatch on every order. Seen it cheaper? Request a price match.
Shipped to your region. Freight is calculated at checkout from live courier rates.
Standard delivery to main‑centre, ground‑floor addresses is included in the quoted rate. For rural or oversized deliveries, any extra freight will be confirmed before dispatch.
Collection available — we'll confirm pickup readiness after your order:
- 136 Cryers Road, East Tāmaki, Auckland 2013
Key Details:
- SKU:
- CNZ-IM-021756
- MPN:
- VS421HDPIP
- Brand:
- StarTech.com
We accept
TechWorld Deal
Genuine NZ stock with full manufacturer warranty — no parallel imports. Hardware only, priced sharp, dispatched fast.
StarTech.com 4-Port HDMI Switch w/Picture-and-Picture
Share an HDMI display between four distinct HDMI audio/video sources, with optional Picture-and-Picture
The VS421HDPIP 4-Port HDMI Video Switch with Picture-and-Picture (PAP) lets you connect four HDMI video sources to a single HDMI display with the added benefit of playing all four video sources on your display simultaneously with combined video.
See the Whole Picture
The split-screen multiplexing switch gives you the flexibility of a 4-port video switch with the added benefit of combining two, three or four video sources onto your output display. The switch supports three different picture-and-picture modes per display: Matrix Mode (1x1) / Dual Mode (2x1) / Quad Mode (4x1) .
Control Your Output
Fitting your boardroom or digital signage application with a VS421HDPIP dramatically increases your communication possibilities. Not only does the picture-and-picture switch increase your communication by a factor of four, but it also enables you to adjust your video sources remotely using your local TCP/IP network, or the included IR remote control.
Increase the Versatility of Your Display
The VS421HDPIP is a flexible video switch that can improve any video display application. The picture-and-picture technology enables you to share up to four distinct images on the same screen, reducing required video real estate and saving you from wasting money on additional displays in a digital signage applications. For security monitoring you can combine four video sources across a single display to view everything more efficiently -- you can even zoom into a single feed for a closer look. For versatile installation options mounting hardware is also included ensuring a tidy professional installation.
The VS421HDPIP is backed by a StarTech.com 2-year warranty, and free lifetime technical support.
The StarTech.com Advantage
- See the whole picture by adding multiple HDMI sources to the same display with picture-and-picture
- Control your output and make your digital signage operation easier with remote control operation using Telnet (TCIP/IP Network), or IR (remote control)
- Increase the versatility of your display and save money, with the picture-and-picture technology reducing the number of displays required with up to four video sources on the same display
The VS421HDPIP 4-Port HDMI Video Switch with Picture-and-Picture (PAP) lets you connect four HDMI video sources to a single HDMI display with the added benefit of playing all four video sources on your display simultaneously with combined video.
See the Whole Picture
The split-screen multiplexing switch gives you the flexibility of a 4-port video switch with the added benefit of combining two, three or four video sources onto your output display. The switch supports three different picture-and-picture modes per display: Matrix Mode (1x1) / Dual Mode (2x1) / Quad Mode (4x1) .
Control Your Output
Fitting your boardroom or digital signage application with a VS421HDPIP dramatically increases your communication possibilities. Not only does the picture-and-picture switch increase your communication by a factor of four, but it also enables you to adjust your video sources remotely using your local TCP/IP network, or the included IR remote control.
Increase the Versatility of Your Display
The VS421HDPIP is a flexible video switch that can improve any video display application. The picture-and-picture technology enables you to share up to four distinct images on the same screen, reducing required video real estate and saving you from wasting money on additional displays in a digital signage applications. For security monitoring you can combine four video sources across a single display to view everything more efficiently -- you can even zoom into a single feed for a closer look. For versatile installation options mounting hardware is also included ensuring a tidy professional installation.
The VS421HDPIP is backed by a StarTech.com 2-year warranty, and free lifetime technical support.
The StarTech.com Advantage
- See the whole picture by adding multiple HDMI sources to the same display with picture-and-picture
- Control your output and make your digital signage operation easier with remote control operation using Telnet (TCIP/IP Network), or IR (remote control)
- Increase the versatility of your display and save money, with the picture-and-picture technology reducing the number of displays required with up to four video sources on the same display
Key features
- Video port type: HDMI
- HDMI ports quantity: 5
- HDMI in: 4
- Number of HDMI outputs: 1
- RS-232 ports: 1
- Material: Aluminium
- Product colour: Black
- Supported graphics resolutions: 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 640 x 480 (VGA)
- Supported video modes: 1080p, 720p
- Maximum resolution: 1920 x 1200 pixels
- Remote control type: RS232, Telnet, IR
- Audio output channels: 7.1 channels
- HD type: Full HD
- AC adapter input voltage: 100 - 240 V
- AC adapter input current: 1 A
- AC adapter output voltage: 12 V
- AC adapter output current: 3 A
- Certification: CE, FCC, TAA, REACH
- Width: 250 mm
- Depth: 435 mm
- Height: 44 mm
- Weight: 2.8 kg
- Package width: 414 mm
- Package depth: 581 mm
- Package height: 141 mm
- Package weight: 4.3 kg
- Remote control included: Yes
- Manual: Yes
- AC adapter included: Yes
- Mounting brackets included: Yes
