STARTECH.COM LC FIBER COUPLER, LC/UPC KEYSTONE JACK
Networking > Network Accessories
- Brand: STARTECH
- Category: Networking
- SKU: DMFKSLCLCCOUPLER
- MPN: DMFKSLCLCCOUPLER
StarTech.com LC to LC Coupler, LC Fiber Coupler, LC/UPC Keystone…
StarTech.com LC to LC Coupler, LC Fiber Coupler, LC/UPC Keystone Jack, Duplex Fiber Optic LC Keystone Coupler for Patch Panel, LC, White, Multi-mode, Single-mode, Acrylonitrile butadiene styrene (ABS), CE, 19 mm
Click or hover over image to enlarge
Number of connectors
2
Connector type
LC
Duplex
Yes
Product colour
White
Fiber mode structure
Multi-mode, Single-mode
Housing material
Acrylonitrile butadiene styrene (ABS)
Compliance certificates
CE
Master (outer) case width
410 mm
Comsys Price
In Stock
8 units available
Shipped NZ‑wide. Freight is calculated at checkout from live courier rates; delivery within Auckland is free on standard‑size items.
Standard delivery to main‑centre, ground‑floor addresses is included in the quoted rate. For rural or oversized deliveries, any extra freight will be confirmed before dispatch.
Four payments of $4.60 per fortnight
Fast dispatch and fair pricing on every order. Found a better offer? Ask for a match.
Secure Checkout
Trusted payment methods and encrypted transactions.
Technical Support
Pre-sales and post-sales support from our team.
Warranty Backed
Local warranty handling and straightforward returns.
STARTECH.COM LC FIBER COUPLER, LC/UPC KEYSTONE JACK
Connect two LC Duplex fiber cables featuring UPC polished ends to extend a network connection, using this LC to LC Keystone Coupler. The female to female fiber coupler maintains optimal signal integrity while achieving low insertion loss that exceeds industry standards.
Compatible with Single Mode and Multimode Fiber Cables
The LC Fiber Coupler supports Single Mode and Multimode LC/LC fiber cables. It is compatible with OS1/OS2 (9/125µm) and OM1/OM2/OM3/OM4/OM5 (62.5/125µm and 50/125µm) fiber core/cladding. The coupler fits securely into the keystone jack which can be installed in a keystone patch panel or wall plate without requiring additional tools.
Durable Construction
The LC/LC Keystone Coupler features a durable ABS housing and ceramic-lined inner sleeves for precise fiber alignment, minimizing signal loss for long-lasting reliability and performance.
The StarTech.com Advantage
Key features
- Number of connectors: 2
- Connector type: LC
- Duplex: Yes
- Product colour: White
- Fiber mode structure: Multi-mode, Single-mode
- Housing material: Acrylonitrile butadiene styrene (ABS)
- Sustainability compliance: Yes
- Compliance certificates: CE
- Width: 19 mm
- Depth: 18 mm
- Height: 20 mm
- Quantity per pack: 1 pc(s)
- Package width: 125 mm
- Package depth: 90 mm
- Package height: 20 mm
- Package weight: 6 g
- Master (outer) case width: 410 mm
- Master (outer) case length: 410 mm
- Master (outer) case height: 230 mm
- Products per master (outer) case: 1000 pc(s)
Inc GST
$18.39
