StarTech.com SFP+ Module - 10G-SFPP-BXD-40K Comp
Brocade 10G-SFPP-BXD-40K Compatible SFP+ Module - 10GBase-BX Fiber Optical Transceiver Downstream (10G-SFPP-BXD-40K-ST)
- Brand: StarTech.com
- Category: Network Accessories
- SKU: 4636510
- MPN: 10G-SFPP-BXD-40K-ST
StarTech.com Brocade 10G-SFPP-BXD-40K Compatible SFP+ Module -…
StarTech.com Brocade 10G-SFPP-BXD-40K Compatible SFP+ Module - 10GBASE-BX-D - 10 GbE Gigabit Ethernet BiDi Fiber (SMF), Fiber optic, 10000 Mbit/s, SFP+, LC, BX-D, 40000 m
Click or hover over image to enlarge
Power consumption (typical)
1.6 W
Product colour
Silver
Hot-swap
Yes
Mean time between failures (MTBF)
646156559 h
Brand compatibility
Brocade
Compatible products
10G-SFPP-BXD-40K
SFP transceiver type
Fiber optic
Maximum data transfer rate
10000 Mbit/s
Comsys Price
Available to Order
Ships in 1–5 business days
Shipped NZ‑wide. Freight is calculated at checkout from live courier rates; delivery within Auckland is free on standard‑size items.
Standard delivery to main‑centre, ground‑floor addresses is included in the quoted rate. For rural or oversized deliveries, any extra freight will be confirmed before dispatch.
Four payments of $18.11 per fortnight
Fast dispatch and fair pricing on every order. Found a better offer? Ask for a match.
Secure Checkout
Trusted payment methods and encrypted transactions.
Technical Support
Pre-sales and post-sales support from our team.
Warranty Backed
Local warranty handling and straightforward returns.
StarTech.com SFP+ Module - 10G-SFPP-BXD-40K Comp
The 10G-SFPP-BXD-40K-ST is a Brocade 10G-SFPP-BXD-40K compatible downstream fiber SFP transceiver which pairs with StarTech.com's 10G-SFPP-BXU-40K-ST. They are designed, programmed and tested to work with 10GBASE-BX compatible Brocade switches and routers. The SFP+ transceiver module supports a maximum distance of up to 40 km (24.8 mi) and delivers dependable 10 GbE connectivity over fiber cabling.
Technical Specifications:
• Wavelength: 1330nmTx/1270nmRx
• Maximum Data Transfer Rate: 10Gbps
• Type: Single Mode Fiber
• Connection Type: LC Connector
• Maximum Transfer Distance: 40 km (24.8 mi)
• MTBF: 646,156,559 hours
• Power Consumption:
• DDM: Yes
This SFP+ fiber module is hot-swappable, making upgrades and replacements seamless by minimizing network disruptions.
StarTech.com SFPs
All StarTech.com SFP & SFP+ transceiver modules are backed by a lifetime warranty and free lifetime multilingual technical support. StarTech.com offers a wide variety of SFP modules and direct-attach SFP Cables, providing the convenience and reliability you need to ensure dependable network performance.
The StarTech.com Advantage
Key features
- SFP transceiver type: Fiber optic
- Maximum data transfer rate: 10000 Mbit/s
- Interface type: SFP+
- Single-mode fiber (SMF) supported: Yes
- Multi-mode fiber (MMF) supported: No
- Fiber optic connector: LC
- SFP transceiver standard: BX-D
- Maximum transfer distance: 40000 m
- Tx wavelength (max): 1330 nm
- Rx wavelength (max): 1270 nm
- Product colour: Silver
- Hot-swap: Yes
- Mean time between failures (MTBF): 646156559 h
- Brand compatibility: Brocade
- Compatible products: 10G-SFPP-BXD-40K
- Power consumption (typical): 1.6 W
- Certification: CE, FCC, UR
- Width: 58.4 mm
- Depth: 13.9 mm
- Height: 12.6 mm
- Weight: 24 g
- Quantity per pack: 1 pc(s)
- Package width: 90 mm
- Package depth: 115 mm
- Package height: 31 mm
- Package weight: 50 g
- Master (outer) case width: 90 mm
- Master (outer) case length: 115 mm
- Harmonized System (HS) code: 85369010
- Master (outer) case height: 31 mm
+ 1 more — see the Specifications tab.
Inc GST
$72.44
