KINGSTON 32GB 3200MT/s DDR4 ECC CL22 SODIMM 2Rx8

32GB 3200MT/s DDR4 ECC CL22 SODIMM 2Rx8 Hynix D

  • Brand: KINGSTON
  • Category: RAM
  • SKU: 6509189
  • MPN: KSM32SED8/32HD

Kingston Technology KSM32SED8/32HD memory module 32 GB 1 x 32 GB…

Kingston Technology KSM32SED8/32HD, 32 GB, 1 x 32 GB, DDR4, 260-pin SO-DIMM

KINGSTON 32GB 3200MT/s DDR4 ECC CL22 SODIMM 2Rx8

Click or hover over image to enlarge

Brand:KINGSTON
MPN:6509189

Part #: 6509189

Search this part on Google

CAS latency

22

Internal memory

32 GB

Memory layout (modules x size)

1 x 32 GB

Internal memory type

DDR4

Memory data transfer rate

3200 MT/s

Component for

Server

Memory form factor

260-pin SO-DIMM

ECC

Yes

Returns & Warranty

Comsys Price

$1,339.74

Available to Order

Ships in 1–5 business days

NZ-wide deliveryNZ Post rates·Ships from Auckland, 1–3 days
1
100% NZ Owned & Operated

Shipped to your region. Freight is calculated at checkout from live courier rates.

Standard delivery to main‑centre, ground‑floor addresses is included in the quoted rate. For rural or oversized deliveries, any extra freight will be confirmed before dispatch.

Add To Compare
We acceptVisaMastercardAmerican ExpressApple PayGoogle PayAfterpay
Afterpay

Four payments of $334.94 per fortnight

Value Deal

Fast dispatch and fair pricing on every order. Found a better offer? Ask for a match.

Secure Checkout

Trusted payment methods and encrypted transactions.

Technical Support

Pre-sales and post-sales support from our team.

Warranty Backed

Local warranty handling and straightforward returns.

KINGSTON 32GB 3200MT/s DDR4 ECC CL22 SODIMM 2Rx8

Kingston's KSM32SED8/32HD is a 4G x 72-bit (32GB) DDR4-3200 CL22 SDRAM (Synchronous DRAM) w/ parity, 2Rx8, ECC, memory module, based on eighteen 2G x 8-bit FBGA components. The SPD is programmed to JEDEC standard latency DDR4-3200 timing of 22-22-22 at 1.2V. Each 260-pin SODIMM uses gold contact fingers.

Key features

  • CAS latency: 22
  • Internal memory: 32 GB
  • Memory layout (modules x size): 1 x 32 GB
  • Internal memory type: DDR4
  • Memory data transfer rate: 3200 MT/s
  • Component for: Server
  • Memory form factor: 260-pin SO-DIMM
  • ECC: Yes
  • Buffered memory type: Unregistered (unbuffered)
  • Memory ranking: 2
  • Memory voltage: 1.2 V
  • Module configuration: 4096M x 72
  • Row cycle time: 45.75 ns
  • Row active time: 32 ns
  • SPD profile: Yes
  • Programming power voltage (VPP): 2.5 V
  • JEDEC standard: Yes
  • Operating temperature (T-T): 0 - 85 °C
  • Storage temperature (T-T): -55 - 100 °C
  • Compliance certificates: RoHS
  • Width: 69.6 mm
  • Depth: 3.7 mm
  • Height: 30 mm

Inc GST

$1,339.74
